MODEL

DIN120-12

DIN120-24

DIN120-48

DIN240-12

DIN240-24

DIN240-48

OUTPUT

DC Output

12V

24V

48V

12V

24V

48V

Rated Current

0~10A

0~5A

0~2.5A

0~16A

0~10A

0~5A

Ripple and Noise

≤100mVp-p

≤100mVp-p

≤150mVp-p

≤100mVp-p

≤100mVp-p

≤150mVp-p

Voltage ADJ. Range

12~14V

24~28V

48~55V

12~14V

24~28V

48~53V

Peak Current

15A

7.5A

3.75A

24A

15A

7.5A

Voltage Accuracy

≤±2%

≤±1%

≤±2%

≤±1%

Line Regulation

≤±1%

Load Regulation

≤±2%

Set-up Time

≤2S( 115Vac&230Vac; full load)

Hold up Time

≥20mS (115/230Vac input; full load)

Temperature Coefficient

≤±0.02%/℃

INPUT

Voltage Range

90~264Vac

Frequency Range

47Hz~63Hz

Power Factor @25℃

≥0.95 @ 100~230Vac (at full load)

Efficiency ( Typical)

12V

24V

48V

12V

24V

48V

≥90.5%

≥92.5%

≥90.5%         ≥92.5%

25℃ @ 220V, full load

AC Current (max.)

＜1.2A@ 110Vac (at full load)

＜2.8A@ 110Vac (at full load)

Inrush Current (Typical)

＜35A@115Vac，＜70A @ 230Vac；25℃

Stand-by Power Consumption

<5W

PROTECTION

Over current

110%~150%@Io

Protection type: Hiccup mode; auto recovery

Over voltage

120%~150%@Vo

Shutdown O/Pvoltage.re-power on to recover

Over temperature

The power supply comes into protection mode when the temperature is greater than 105 °C

Short Circuit

Long-term mode, auto recovery

ENVIRONMENT

Operating amb. Temp. & Hum.

-40℃~70℃; 20%~90%RH No condensing (refer to derating curve)

Storage Temp. & Hum.

-40℃~85℃; 10%~95%RH No condensing

Vibration

9-200Hz, 10m/s2; 3.5min./1cycle, 5 periods, each along x, y, z axes

Impulse

250m/s2, 6ms; 3 times, each along x, y, z axes

Altitude

5000m
